H Class-  Homeowner Models

PT-180   600 lbs. Lift Capacity                   NOT FOR COMMERCIAL USE

General Features

- 600 lbs. Lift Capacity

- 4' 2" Lift Height

- 18 Horsepower Gasoline Engine

- 4-Wheel Hydrostatic Drive

- 20+ Attachments Available

- Manual Operated Quick Attach

- Articulated Steering

- Tractor Width 42"

- Price Information

- H Class Video



Control Panel

Treadle

Levers





PT-180 Specifications

Engine- Gasoline 18 Horsepower
Weight- 1,260 lbs.
Width- 42"
Length- 83" from front tire to rear of tractor
Speed- 0-8 mph Infinitely Variable
Frame- 3/16" to 3/8"
PTO- 8 GPM @ 2,000 PSI
Fuel Tank- 5 Gallon
Hydraulic Oil Tank- 10 Gallon 10W40
Lift Capacity- 600 lbs.
Lift Height- 4' 2"
Inside Turning Radius- 36"
Outside Turning Radius- 92"
Wheel Base- 48"
ROPS- n/a
Oil Cooler/Fan- n/a
Quick Attach- Manual Actuated
Tires- 23-8:50x12 Turf or Bar













PT-422  800 lbs. Lift Capacity  422                NOT FOR COMMERCIAL USE

General Features

- 800 lbs. Lift Capacity

- 4' 4" Lift Height

- 22 Horsepower Gasoline Engine

- 4-Wheel Hydrostatic Drive

- 40 Attachments Available

- Hydraulic Operated Quick Attach

- Articulated Steering

- Tractor Width 45"

- Price Information

- H Class Video







422 Control Panel

Steering wheel, joystick, throttle/choke, light switch, PTO switch, ignition, auxiliary PTO, park brake

Treadle

Press right pedal to go forward; Press left pedal to go reverse; Centering treadle stops the machine and acts as a service brake.

Engine

22 Horsepower Gasoline Engine




PT-422 Specifications

Engine- Gasoline 22 Horsepower
Weight- 1,344 lbs.
Width- 45"
Length- 83" from front tire to rear of tractor
Speed- 0-8 mph Infinitely Variable
Frame- 3/16" to 3/8" Steel Plate
PTO- 8 GPM @ 2,500 PSI
Fuel Tank- 5 Gallon Capacity
Hydraulic Oil Tank- 10 Gallon 5W30
Lift Capacity- 800 lbs.
Lift Height- 4' 4"
Inside Turning Radius- 36"
Outside Turning Radius- 92"
Wheel Base- 48"
Tires- 23-10:50x12
Oil Cooler/Fan- Standard








T8 Class
